KL-BC127 Physiotherapy Table — Electric Multi-Section Table for Physiotherapy and Rehabilitation

Quick answer. The Keling KL-BC127 is an electric physiotherapy table measuring 1940 × 700 mm with a height range of 490–890 mm, a back plate adjusting 88°/40° and a leg plate adjusting 50°/45°, driven by electric height adjustment with optional castors. It is manufactured by Keling Medical (Jiangsu Keling Medical Appliances Co., Ltd.) for physiotherapy clinics and rehabilitation departments.

External size (L × W): 1940 × 700 mm
Table height range: 490–890 mm
Back plate adjustment: 88° (up) / 40° (down)
Leg plate adjustment: 50° (up) / 45° (down)

Markdown

ISO 13485:2016 CE (EU MDR) Global export OEM available

Overview

The KL-BC127 physiotherapy table is designed for the rigorous positional demands of professional physiotherapy and rehabilitation practice. Its 1940 × 700 mm treatment surface is wider and longer than standard examination tables, providing the space needed for full-body musculoskeletal assessments, manual therapy techniques and active-assisted exercise programs conducted on the table surface.

The multi-directional section adjustments are the distinguishing clinical feature. The back plate moves through 88° forward and 40° rearward — providing a range from near-vertical to inclined-back that covers the positions required for shoulder, cervical and upper limb assessment and treatment. The leg plate adjusts 50° forward and 45° rearward, enabling knee flexion assessment, hamstring lengthening positions and lower limb techniques that require the leg section to move independently from the trunk.

Electric height adjustment from 490 mm to 890 mm allows the physiotherapist to work at a biomechanically appropriate height for each technique: lower for traction and manual therapy requiring downward force, and higher for lighter assessment work performed standing. This 400 mm range removes the posture compromise associated with fixed-height treatment plinths and supports sustainable clinical practice over a full working day.

Quick facts

The Keling KL-BC127 is a multi-section physiotherapy table designed for professional physiotherapy and rehabilitation treatment.
Surface dimensions are 1940 × 700 mm; electric height adjusts from 490 mm to 890 mm for therapist ergonomic positioning.
The back plate adjusts to 88° (forward) and 40° (rearward); the leg plate adjusts to 50° (forward) and 45° (rearward) for multi-directional positioning.
Electric height adjustment allows the therapist to set the working height without manual effort between patients.
The face hole in the head section accommodates prone-position treatment without neck discomfort.
Optional castors allow repositioning between treatment bays.

Key features

Electric height adjustment 490–890 mm
400 mm motorized height range enables optimal therapist positioning for different manual therapy techniques and patient body sizes.
Back plate adjustment 88°/40°
extensive range from near-vertical to reverse-inclined position supports upper limb, shoulder and cervical physiotherapy techniques.
Leg plate adjustment 50°/45°
independent forward and rearward leg section control for lower limb assessment, hamstring and hip techniques.
Wide 1940 × 700 mm surface
generous treatment surface accommodates full-body assessment and manual therapy without patient overhang.
Face hole in head section
integral face recess enables prone-position treatment without client neck rotation discomfort.
Optional castors
enable repositioning between bays in multi-treatment physiotherapy departments.
Customizable color
upholstery color specified to match clinic or department branding.

Technical specifications

Specifications are subject to change; dimensional tolerances may apply. Contact Keling Medical for the latest datasheet.

9 parameters for KL-BC127

KL-BC127 technical specifications
Model	KL-BC127
Product type	Physiotherapy table
External size (L × W)	1940 × 700 mm
Table height range	490–890 mm
Back plate adjustment	88° (up) / 40° (down)
Leg plate adjustment	50° (up) / 45° (down)
Height adjustment	Electric
Castors	Optional
Color	Customizable

Applications

The KL-BC127 is suited for physiotherapy departments in hospitals and clinics, private physiotherapy practices, sports medicine facilities, rehabilitation centers, chiropractic offices and orthopedic outpatient departments. Its multi-directional section adjustments and electric height range make it appropriate for the full range of physiotherapy assessment and treatment techniques.

Questions buyers ask

What is the Keling KL-BC127 physiotherapy table used for?

The KL-BC127 is a professional physiotherapy treatment table for musculoskeletal assessment, manual therapy and rehabilitation exercises. Its multi-directional back and leg plate adjustments, 400 mm electric height range and wide treatment surface support the full range of physiotherapy techniques from cervical manual therapy to lower limb rehabilitation.

What do the back plate and leg plate adjustment angles mean clinically?

The back plate on the KL-BC127 raises 88° (near-vertical for seated examination or upper limb work) and lowers 40° (head-down tilt for spinal traction and declination techniques). The leg plate raises 50° (for active knee flexion assessment and hamstring techniques) and lowers 45° (for prone hip extension and posterior chain work). These multi-directional capabilities make the KL-BC127 significantly more versatile than a simple back-raising examination table.

What is the height range of the KL-BC127 electric adjustment?

The KL-BC127 adjusts electrically from 490 mm to 890 mm — a 400 mm range. This covers the standard ergonomic working heights for physiotherapy: 490 mm allows a therapist to perform traction or stabilization techniques with good mechanical advantage, while 890 mm provides a standing working height appropriate for lighter assessment and exercise techniques.

Can the KL-BC127 be supplied for a multi-bay physiotherapy department?

Yes. Keling Medical supplies physiotherapy departments and medical equipment distributors worldwide. The KL-BC127 is available with optional castors for multi-bay use and with customizable upholstery color for departmental coordination. Contact Keling Medical via https://www.kelingmed.com for bulk pricing.
