KL-6 Series Orthopaedics Tractor — Carbon Fiber Traction Frame for Fracture and Dislocation Surgery

Quick answer. The Keling KL-6 Series (primary model KL-6C) is a carbon fiber orthopaedics traction frame measuring 1700 ± 10 mm long × 750 ± 100 mm wide, with traction device horizontal rotation 0–180°, traction distance (0–200 mm) ± 10%, traction device height adjustment ≥400 mm, clear fluoroscopic imaging capability and plug-in connection to compatible operating tables. Manufactured by Keling Medical (Jiangsu Keling Medical Appliances Co., Ltd.) for orthopaedic fracture and dislocation surgery.

Traction device height adjustment: ≥400 mm
Length: 1700 ± 10 mm
Width: 750 ± 100 mm
Traction distance: (0–200 mm) ± 10%

Request a quote Email sales WhatsApp

Markdown

ISO 13485:2016 CE (EU MDR) Global export OEM available

Overview

The Keling KL-6 Series orthopaedics tractor is a specialist surgical attachment designed for the operative treatment of fractures and dislocations — particularly of the lower extremity — where controlled axial traction and precise limb positioning are required throughout the surgical procedure. The traction frame plugs directly into compatible Keling operating tables via a quick plug-in connection, creating an integrated orthopaedic surgical system without the need for a dedicated fracture table in every theatre.

Carbon fiber construction is the defining material choice for the KL-6C. Unlike stainless steel or aluminium traction frames, carbon fiber is fully radiolucent — it appears transparent on fluoroscopy and C-arm imaging, delivering clear, artefact-free intraoperative images of the surgical field, fracture reduction and implant placement. This characteristic is essential for procedures such as intramedullary nailing of femoral and tibial fractures, femoral neck fixation and hip arthroplasty revisions where real-time fluoroscopy guides the surgical technique.

The traction mechanism provides 0–180° horizontal rotation for limb positioning, 0–200 mm of axial traction distance for fracture reduction, and ≥400 mm of height adjustment to accommodate patients of different stature and limb length. The included accessory car allows the traction frame to be moved conveniently between theatres and stored compactly when not in use, making it practical even in facilities that use it only periodically.

Quick facts

The Keling KL-6 Series orthopaedics tractor uses carbon fiber material, providing clear fluoroscopic imaging for intraoperative C-arm use.
The primary model is KL-6C; it measures 1700 ± 10 mm long and 750 ± 100 mm wide.
Traction device horizontal rotation range is 0–180°; traction distance is (0–200 mm) ± 10%; height adjustment is ≥400 mm.
The plug-in design connects conveniently and quickly to compatible operating tables, including the KL-D·III-III.
An accessory car (traction frame trolley) is included for convenient movement and space-efficient storage.
The KL-6 Series is manufactured by Keling Medical, a Jiangsu-based surgical equipment producer established in 1996.

Key features

Carbon fiber construction
high-strength, lightweight carbon fiber is fully radiolucent for clear fluoroscopic and C-arm imaging without interference or artefacts during surgery.
0–180° horizontal rotation
wide rotational range of the traction device enables precise limb positioning for varied fracture patterns and surgical approaches.
0–200 mm traction distance
controlled axial traction for fracture reduction; adjustable in small increments with ±10% tolerance for fine positioning.
≥400 mm height adjustment
extensive vertical adjustment accommodates patients across a wide range of stature and limb length for consistent surgical access.
Plug-in table connection
convenient, quick-connect plug-in system attaches securely to compatible Keling operating tables including the KL-D·III-III, eliminating the need for a dedicated fracture table.
Traction frame accessory car
included trolley provides convenient, space-efficient movement and storage of the traction frame between cases and theatres.
Lightweight high-strength structure
carbon fiber provides strength equivalent to stainless steel at significantly reduced weight, reducing setup effort and handling load.

Technical specifications

Specifications are subject to change; dimensional tolerances may apply. Contact Keling Medical for the latest datasheet.

9 parameters for KL-6 / KL-6C

KL-6 / KL-6C technical specifications
Model	KL-6C
Length	1700 ± 10 mm
Width	750 ± 100 mm
Traction device horizontal rotary	0–180°
Traction distance	(0–200 mm) ± 10%
Traction device height adjustment	≥400 mm
Material	Carbon fiber
Connection type	Plug-in (compatible with KL-D·III-III and other operating tables)
Included accessories	Traction frame accessory car

Applications

The KL-6 Series orthopaedics tractor is used in orthopaedic operating theatres for fracture and dislocation surgery including intramedullary nailing of femoral and tibial fractures, femoral neck screw fixation, hip arthroplasty, ankle and lower extremity fracture reduction, and traction and reduction procedures under fluoroscopic guidance. It can be used in combination with various Keling operating tables to create a complete orthopaedic surgical system.

Questions buyers ask

What is the Keling KL-6 Series orthopaedics tractor used for?

The KL-6 (KL-6C) is a carbon fiber traction frame for orthopaedic surgery involving fractures and dislocations. It attaches to compatible operating tables to provide controlled axial traction, limb rotation and height positioning for intramedullary nailing, fracture fixation and reduction procedures under intraoperative fluoroscopy.

Why is carbon fiber used for the KL-6C traction frame?

Carbon fiber is fully radiolucent, meaning it does not obstruct or create artefacts in C-arm or fluoroscopic images during surgery. This provides surgeons with clear, unobstructed intraoperative imaging of fracture reduction and implant placement. Carbon fiber also offers high strength at low weight, reducing setup and handling effort.

How does the KL-6C connect to the operating table?

The KL-6C uses a convenient plug-in design that attaches quickly and securely to compatible Keling operating tables, including the KL-D·III-III model. The quick-connect system allows the traction frame to be attached before surgery and removed easily for cleaning and storage via the included accessory car.

Is the KL-6 available for international export and bulk purchase?

Yes. Keling Medical exports orthopaedic surgical accessories and operating tables to hospitals and distributors worldwide through its Shanghai sales and export center. Bulk and project orders are available. Contact Keling Medical at https://www.kelingmed.com for pricing and table compatibility information.
